Z-3272 Plus delivers blazing speed on 1D and 2D barcodes, allowing you to accommodate 2D barcodes without sacrificing scanning quality or performance. With our technology, users no longer need to worry about aligning the barcode with the scanner or pausing between scans. Whether it's a damaged or poorly printed barcode, our true point-and-shoot first-time scanning simplicity ensures that you get accurate results every time. Additionally, the scanner is designed to be durable and reliable, making it a perfect solution for everyday use.
• High speed, omnidirectional reading of 1D, 2D, and postal barcodes
• Hands-free mode activates automatically when placed on the stand
• Long press the trigger to scan fast-moving labels
• Reads barcode reliably off cell phone screens
• Extremely low power consumption
• Two cabling options: USB or RS-232
• Durable over-molded housing and secured cable ensure drop/shock survivability
• Healthcare label compliance: Supports GS1 and FMD format
• IP42 protection against moisture and dust
| Aiming Element | ||
|---|---|---|
| 617nm visible LED | ||
| Illumination Element | ||
| 617nm visible LED | ||
| Optical System | ||
| CMOS | ||
| Image Sensor | ||
| 1280 x 800 | ||
| Depth of Field | ||
| Code 39 (3 mil): 50 - 80 mm, Code 39 (5 mil): 50 - 150 mm, UPC/EAN (13 mil): 30 - 280 mm | ||
| Min. Bar Width | ||
| 3 mil (Code39) | ||
| Scan Angle | ||
| 38.6° horizontal; 24.9° vertical | ||
| Print Contrast | ||
| 30% @ UPC/EAN 100% | ||
| Indicator | ||
| Two-color LED (blue, red) | ||
| Programmable Operation | ||
| Scan mode, Beeper tone | ||
| System Interface | ||
| RS-232, USB | ||
| Dimensions H x W x L | ||
|---|---|---|
| 180.0 × 70.0 × 107.0 mm (device only) | ||
| Weight (g) | ||
| 150 g | ||
| Cable | ||
| Standard 2M straight | ||
| Input Voltage | ||
|---|---|---|
| 5 VDC ±10% | ||
| Operating Current | ||
| 230 mA @ 5V ( Typical ) | ||
| EMC | ||
|---|---|---|
| CE & FCC DOC compliant; VCCI; BSMI | ||
| Safety | ||
| IEC 62471 Exempt | ||
| Operating Temperature | ||
|---|---|---|
| 0°C – 50°C (32°F – 122°F) | ||
| Storage Temperature | ||
| -20°C – 60°C (-4°F – 140°F) | ||
| Humidity | ||
| 5% – 95% RH (non-condensing) | ||
| Light Level | ||
| 0 - 100,000 Lux ( fluorescence ) | ||
| Drop Durability | ||
| Designed to withstand 1.5M drops | ||
| Environmental Sealing | ||
| IP42 | ||
| 1D Barcode | ||
|---|---|---|
| UPC/EAN [UPCA/UPCE/ EAN-8/ EAN-13, ISBN (Bookland),ISSN], Code 39 (Standard, Full ASCII, Trioptic, Code 32 (ItalianPharmacode), Code 128, Code 93, Codabar, 2 of 5 (Interleaved2 of 5, Discrete 2 of 5, IATA, Chinese 2 of 5, Matrix 2 of 5, Code11), MSI Plessey, GS1 DataBar (Omnidirectional, Truncated,Stacked, Stacked Omnidirectional, Limited, Expanded, Expanded Stacked) | ||
| 2D Barcode | ||
| PDF417, MicroPDF417, Composite Codes(CC-A, CC-B, CC-C) , Aztec (Standard, Inverse),Maxicode, Data Matrix/ ECC 200 (Standard, Inverse), QR Code(Standard, Inverse, Micro) | ||
